Edwards Barocel: The gold standard of accurate measurement!
With accuracies of up to 0.15%, these gauges are commonly used to control systems in diverse processes, from industrial furnaces to semi-conductor manufacturing.
As part of the Active gauge family, they have a 0-10V linear output which can be simply converted to a pressure reading.
Available in three main variants: miniature, standard, and heated, as well as with varying full scale ranges, you can accurately control from atmosphere to 1e-4mbar.
Accuracy ranging from 1% for the miniature to 0.15% for the heated versions
The ability to output a linear 0-10V signal or communicate via RS232 for more detailed and direct control
Accuracy and reliable control
With all our offerings having multiple full scales, choosing the gauge which covers your process range is simple.
You can also rest easy knowing that the gauges have multiple protections against contaminants (integrated baffle, ceramic coating, diaphragm shield) and have market leading resistance against zero drift.
Controllers – local display and control of your system
If you require a local display for these gauges, we offer a special variant of our TIC controller which can operate with all of the Barocel gauges, alongside our standard Active gauges.
With the ability to connect a total of 6 gauges at any one time (maximum of 3 Barocel gauges depending on heated/unheated) you can cover multiple areas of your system with a single controller.
Low cost of ownership
no maintenance required – no additional costs!
Dual onboard set point
ability to trigger actions via the onboard set points
suitable for load lock/harsh processes due to rugged sensor design
